Exploratory Data Analysis (EDA)

Automatic Car Classification with AI

TEAM 1 :
Enzo Gianotti
Nicolas Passadore
Carlos Alberto Gómez Prado
Nahuel Garcia
Agustin Genoud
Jhoeel Luna

Table of contents

Objective : visualize and make the right decisions to clean the data set.

1. Preparation

1.1 Import libraries

1.2 Data Processed

• 1.2.1 Download & Preprocessing

1.3 Quick view of images

• 1.3.1 Quick view of images RD(0)
• 1.3.2 Quick view of images P(1)
• 1.3.3 Quick view of images P(2)
• 1.3.4 Quick view of images P(3)

1.4 Data extraction

• 1.4.1 Create a data frame P(0)
• 1.4.2 Create a data frame P(1)
• 1.4.3 Create a data frame P(2)
• 1.4.4 Create a data frame P(3)

2. EDA

• 2.1 Visualization
  • 2.1.1 Multivariable
    • 2.1.1.1 Box plots
    • 2.1.1.2 Bar Plots
    • 2.1.1.3 Stacked graphics
    • 2.1.1.4 Correlation matrix
    • 2.1.1.5 Heatmap
  • 2.1.2 Univariable
    • 2.1.2.1 Top 25 Bar plots
• 2.2 Experiments
  • 2.2.1 Missing or corrupted data
  • 2.2.2 About Models

3. pandas-profiling

• 3.1 Report RD(0)
• 3.2 Report P(1)
• 3.3 Report P(2)
• 3.4 Report P(3)

4. Resources

• 4.1 Methodology
• 4.2 Links
• 4.3 Libs
• 4.4 Papers

5. Conclusions

• 5.1 Research
• 5.2 Raw Data
• 5.3 Preprocessing
• 5.4 Final conclusions

---

1. Preparation

1.1 Import libraries

import PIL
from PIL import Image
import glob
import sys
import os
import datetime
import pandas as pd
import pandas_profiling
from pandas_profiling import ProfileReport
from pandas_profiling.utils.cache import cache_file
import pathlib
import matplotlib.pyplot as plt
import seaborn as sns
import cv2
import numpy as np
import random
import tensorflow as tf
from tensorflow.keras.preprocessing import image
from tensorflow.keras.applications import imagenet_utils
from IPython.display import Image
from tensorflow import keras
from  matplotlib import pyplot as plt
import matplotlib.image as mpimg
%matplotlib inline
import warnings
warnings.filterwarnings('ignore')

FOLDER_RD = "/mnt/data/nahuel/images/"
FOLDER_P1_TRAIN = "/mnt/data/dataset_v1/train"
FOLDER_P2_TRAIN = "/mnt/data/dataset_v2/train"
FOLDER_P2_TEST = "/mnt/data/dataset_v2/test"
FOLDER_P3_TRAIN = "/mnt/data/dataset_v3/train"
FOLDER_P3_TEST = "/mnt/data/dataset_v3/test"

def quick_plot(data, kind,alpha,cmap ='RdBu_r',):
    '''return grapphic plot and describe data'''
    plt.style.use('ggplot')
    sns.set_style('darkgrid')
    plt.xlabel('Brand')
    plt.ylabel('Count')
    plt.title('Class distribution')
    data.groupby("brand")["model"].count().sort_values(ascending=False).plot(kind=kind,
                                                                                alpha=alpha,
                                                                                cmap='RdBu_r',
                                                                                figsize =(15,6),
                                                                                legend=True,
                                                                                linewidth=2.0)
    data_group = pd.DataFrame(data.groupby('brand')["model"].count().sort_values(ascending=False),
                              columns=['model'])
    plt.show()
    print(data_group.T ,'\n')
    print(data_group.describe().T)

def display_one_image(dir_,image):
    '''print type , shape , min max ,
    px, path and dir count_inage'''
    data_dir = dir_
    image_count = len(list(data_dir.glob('*/*.jpg')))
    img = image
    img_rgb = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
    plt.imshow(img_rgb)
    plt.show()
    print(f'Image type: {type(img)}')
    print(f'Image shape: {img.shape} (Height x Width x Channels)')
    print(f'Image min value: {img.min()}')
    print(f'Image max value: {img.max()}')
    # We can access to pixel values
    px = img[100,100]
    print(px)
    print('Path: ',data_dir)
    print('Total images: ',image_count)

def display_images(img_folder,size=(20,20)):
    '''Check the number of:
    1. Samples 5 random images.
    2. Samples Number of images'''
    plt.figure(figsize=size)
    for i in range(5):
        file = random.choice(os.listdir(img_folder))
        image_path= os.path.join(img_folder, file)
        img=mpimg.imread(image_path)
        ax=plt.subplot(1,5,i+1)
        plt.imshow(img)

    initial_count = 0
    for path in os.listdir(img_folder):
        if os.path.isfile(os.path.join(img_folder, path)):
            initial_count += 1
    print("Total images: ", initial_count)

def create_data(image_folder , n = 0):
    ''' Passing the image_folder returns
    a dataframe with filename ,
    brand, model ,
    if c ==1 year'''
    filenames = []
    for class_name in os.listdir(image_folder):
        class_folder = os.path.join(image_folder, class_name)
        for image in os.listdir(class_folder):
            filename = os.path.join(class_folder, image)
            filenames.append(filename)

    data = pd.DataFrame(filenames, columns=['filename'])
    data['filename'].str.split("/")
    data['brand'] = data['filename'].str.split("/").str[-2].str.split("_").str[0]
    data['model'] = data['filename'].str.split("/").str[-2]
    if (n == 1):
        data['model'] = data['filename'].str.split('/').str[-2].str.split('_').str[1]
        data['year'] = data['filename'].str.split('/').str[-2].str.split('_').str[2]
    return data

def plot_multi_boxplot_swarmpplot(data, size = (15,8)):
    '''show boxplot and swarmplot'''
    plt.style.use('ggplot')
    sns.set_style('darkgrid')
    plt.figure(figsize=size)
    sns.swarmplot(data = data.groupby("brand").count(),
                  split = True,
                  color ='white',
                  linewidth=2.0,
                  orient='h',
                  alpha=0.9)

    sns.boxplot(data = data.groupby("brand").count(),
                palette ='RdBu_r',
                orient='h',
                linewidth=2.0)
    plt.xlabel('Count')
    plt.title('Data distribution')
    plt.show()
    print(data.groupby("brand").count().T)

def Stacking_graphs(data,class_name,k=True):
    '''show  plot stack'''
    plt.style.use('ggplot')
    sns.set_style('darkgrid')
    plt.figure(figsize=(15,5))
    plt.title('Stacking Per ' + class_name)
    plt.xlabel('')
    sns.histplot(data.groupby(class_name).count(),
                 palette ='RdBu_r',
                 linewidth=3.0 ,
                 bins= 30,
                 legend=True,
                 stat ='count',
                 multiple="stack",
                 kde=k,
                 alpha=0.80)
    plt.show()

def plot_matrix(data,class_name,n=1):
    '''show  heatmap'''
    plt.style.use('ggplot')
    sns.set_style('darkgrid')
    if (n==1):
        plt.figure(figsize=(10,5))
        plt.title('Correlation matrix')
        sns.heatmap(data.groupby(class_name).count().corr(),
                    annot=True,
                    fmt='.1f',
                    linewidth=.3,
                    cmap='rocket_r')
    else :
        fig, ax = plt.subplots(figsize = (12,12))
        ax.set(xlabel="", ylabel="")
        ax.xaxis.tick_top()
        sns.heatmap(data.groupby(class_name).count(),
                    cmap='rocket_r',
                    annot=False , fmt=".1f",linewidth=.5)
    plt.show()

def univ_dist(data,name,size=(5,5)):
    '''barplot
    distributions'''
    plt.style.use('ggplot')
    sns.set_style('darkgrid')
    plt.figure(figsize=size)
    plt.xlabel('Count')
    plt.title('Absolute frequencies of ' + name)
    pd.value_counts(data[name]).sort_values(ascending=False).head(25).plot(kind='barh',
                                                                                  cmap ='RdBu_r',
                                                                                  linewidth=3.0,
                                                                                  alpha=0.75,
                                                                                  width=1)

    plt.show()
    if (name != 'filename'):
        print(pd.DataFrame(data.groupby(name)["model"].count().sort_values(ascending=False).head(25),
                           columns=['model']).T)
    pd.DataFrame(100 * data[name].value_counts() / len(data[name])).sort_values(by = [name],
                                                                                      ascending=(False)).head(25).plot(kind='barh',
                                                                                                                       figsize=(5,5),
                                                                                                                       cmap ='tab20',
                                                                                                                       linewidth=3.0,
                                                                                                                       alpha=0.6,
                                                                                                                       width=1)
    plt.xlabel('Percentage (%)')
    plt.title('Relative frequencies of '+ name)
    plt.show()
    if (name != 'filename'):
        print(pd.DataFrame(100 * data[name].value_counts() / len(data[name])).sort_values(by =  [name],
                                                                                          ascending=(False)).head(25).T)

def info_data(data):
    '''show info '''
    print(data.info(),'\n')
    print(data.isnull().sum(),'\n')
    quick_plot(data, kind="area",alpha=0.3)
    quick_plot(data, kind="bar",alpha=0.75)

def all_class_plots(data):
    '''show bar plot'''
    plt.figure(figsize=(15,15))
    plt.title('Distribution of all brands')
    cat_totals = data.groupby("brand")["model"].count().sort_values()
    cat_totals.plot(kind="barh", fontsize=8,alpha=0.75,cmap ='RdBu_r',width=0.8)
    plt.show()

def Samples_info(data_dir_train,data_dir_test):
    '''return tuple size train, test, and total'''
    count_train = len(list(data_dir_train.glob('*/*.jpg')))
    count_test = len(list(data_dir_test.glob('*/*.jpg')))
    total = count_train + count_test
    return count_train , count_test , total

def convert_data(data):
    '''return dataframe transpose'''
    data = pd.DataFrame(data).T
    data.rename(columns={0:'Train',
                              1:'Test',
                              2:'Total'},
                              inplace=True)
    return data

/usr/lib/python3/dist-packages/OpenSSL/crypto.py:12: CryptographyDeprecationWarning: Python 3.6 is no longer supported by the Python core team. Therefore, support for it is deprecated in cryptography and will be removed in a future release.
  from cryptography import x509

1.2 Data Processed

1.2.1 Download & Preprocessing
The notebooks used will be available in the project's notebook folder, as well as a link to Gitlab dataset_cleaning.

1.3 Quick view of images

• 1.3.1 Quick view of images RD(0)

Random display of the first 5 images.

• Class : abarth_124-spider_2016

img_folder=r'/mnt/data/nahuel/images/abarth_124-spider_2016/'
display_images(img_folder)

Total images:  243

• Image structure RD(0)

data_dir = pathlib.Path(r'/mnt/data/nahuel/images/')
img = cv2.imread('/mnt/data/nahuel/images/abarth_124-spider_2016/905_7_7d71c74b-ed3d-c603-e053-e250040a6889_f26b7bc7-95ff-4012-bf97-e386e657bf48.jpg')
display_one_image(data_dir,img)

Image type: <class 'numpy.ndarray'>
Image shape: (480, 640, 3) (Height x Width x Channels)
Image min value: 0
Image max value: 255
[77 74 66]
Path:  /mnt/data/nahuel/images
Total images:  1631955

• This version did not yet have a test set, Total images for RD(0) is 1631955

• 1.3.2 Quick view of images P(1)

Random display of the first 5 images.

• Class : porsche_911

img_folder=r'/mnt/data/dataset_v1/train/porsche_911/'
display_images(img_folder)

Total images:  200

• Image structure P(1)

data_dir_train = pathlib.Path(r'/mnt/data/dataset_v1/train/')
img = cv2.imread('/mnt/data/dataset_v1/train/porsche_911/39978_3_8efe016c-d00f-c14d-e053-e350040a0db0_862dacbd-567c-47d6-aede-8583ebea3cfe.jpg')
display_one_image(data_dir_train,img)

Image type: <class 'numpy.ndarray'>
Image shape: (236, 433, 3) (Height x Width x Channels)
Image min value: 0
Image max value: 255
[82 79 75]
Path:  /mnt/data/dataset_v1/train
Total images:  130197

• This version did not yet have a test set, Total images for P(1) 130197.

• 1.3.3 Quick view of images P(2)

Random display of the first 5 images.

• Class : porsche_900_series

img_folder=r'/mnt/data/dataset_v2/train/porsche_911/'
display_images(img_folder)

Total images:  171

• Image structure Train P(2)

data_dir_train = pathlib.Path(r'/mnt/data/dataset_v2/train/')
img = cv2.imread('/mnt/data/dataset_v2/train/porsche_911/39976_3_f0006f61-3068-164e-e053-e350040aa153_a0170772-0984-427d-a309-767eb942eeef.jpg')
display_one_image(data_dir_train,img)

Image type: <class 'numpy.ndarray'>
Image shape: (346, 455, 3) (Height x Width x Channels)
Image min value: 0
Image max value: 255
[137 155 156]
Path:  /mnt/data/dataset_v2/train
Total images:  65312

• Image structure Test P(2)

data_dir_test = pathlib.Path(r'/mnt/data/dataset_v2/test/')
img = cv2.imread('/mnt/data/dataset_v2/test/porsche_911/39870_2_9113c4a3-3f67-4d27-8611-6fec78450fcd_2b1542cc-fcbe-495a-a650-8a19f54dfef4.jpg')
display_one_image(data_dir_test,img)

Image type: <class 'numpy.ndarray'>
Image shape: (236, 496, 3) (Height x Width x Channels)
Image min value: 0
Image max value: 255
[172 166 159]
Path:  /mnt/data/dataset_v2/test
Total images:  7257

P2_samples = convert_data(Samples_info(data_dir_train,data_dir_test))
P2_samples

	Train	Test	Total
0	65312	7257	72569

The total samples are 72569 for P(2).

• 1.3.4 Quick view of images P(3)

Random display of the first 5 images.

• Class : porsche_900_series

img_folder=r'/mnt/data/dataset_v3/train/porsche_900_series/'
display_images(img_folder)

Total images:  346

• Image structure Train P(3)

data_dir_train = pathlib.Path(r'/mnt/data/dataset_v3/train/')
img = cv2.imread('/mnt/data/dataset_v3/train/porsche_900_series/40480_14_680571fe-d8db-422a-94c1-c0a3b66ea2a9_193880c5-2cb4-47bf-9833-ceeb13c79d20.jpg')
display_one_image(data_dir_train,img)

Image type: <class 'numpy.ndarray'>
Image shape: (383, 620, 3) (Height x Width x Channels)
Image min value: 0
Image max value: 255
[247 252 251]
Path:  /mnt/data/dataset_v3/train
Total images:  65312

• Image structure Test P(3)

data_dir_test = pathlib.Path(r'/mnt/data/dataset_v3/test/')
img = cv2.imread('/mnt/data/dataset_v3/test/lexus_ct-200h/20595_7_549802ba-ce39-47f5-b8b4-86fece3d964d_5222cb28-8ca3-4d1a-93bc-40b6ab26384d.jpg')
display_one_image(data_dir_test,img)

Image type: <class 'numpy.ndarray'>
Image shape: (400, 547, 3) (Height x Width x Channels)
Image min value: 0
Image max value: 255
[25 12 10]
Path:  /mnt/data/dataset_v3/test
Total images:  7257

P3_samples = convert_data(Samples_info(data_dir_train,data_dir_test))
P3_samples

	Train	Test	Total
0	65312	7257	72569

The total samples are 72569 for P(3).

1.4 Data extraction

• 1.4.1 Create a data frame RD(0)

Extraction of a list of classes and storage in CSV from the image directory.

df_RD = create_data(FOLDER_RD,1)
df_RD.head()

	filename	brand	model	year
0	/mnt/data/nahuel/images/abarth_124-spider_2016...	abarth	124-spider	2016
1	/mnt/data/nahuel/images/abarth_124-spider_2016...	abarth	124-spider	2016
2	/mnt/data/nahuel/images/abarth_124-spider_2016...	abarth	124-spider	2016
3	/mnt/data/nahuel/images/abarth_124-spider_2016...	abarth	124-spider	2016
4	/mnt/data/nahuel/images/abarth_124-spider_2016...	abarth	124-spider	2016

df_RD.nunique()

filename    1632113
brand            57
model           823
year             19
dtype: int64

• Structure and quick view RD(0)

info_data(df_RD)

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 1632113 entries, 0 to 1632112
Data columns (total 4 columns):
 #   Column    Non-Null Count    Dtype
---  ------    --------------    -----
 0   filename  1632113 non-null  object
 1   brand     1632113 non-null  object
 2   model     1632113 non-null  object
 3   year      1632113 non-null  object
dtypes: object(4)
memory usage: 49.8+ MB
None

filename    0
brand       0
model       0
year        0
dtype: int64

brand  mercedes-benz     bmw  volkswagen   audi   fiat  citroen  renault  \
model         230990  147449      130423  81760  72367    68487    68458

brand   ford   mini   opel  ...  aston-martin  tesla  hummer  isuzu    mg  \
model  67695  64446  59877  ...          2214   2206    1532   1448  1038

brand  ligier  rover  corvette  lada  cadillac
model     753    603       287   272       253

[1 rows x 57 columns]

       count          mean           std    min     25%      50%      75%  \
model   57.0  28633.561404  41410.185854  253.0  4854.0  13861.0  31336.0

            max
model  230990.0

brand  mercedes-benz     bmw  volkswagen   audi   fiat  citroen  renault  \
model         230990  147449      130423  81760  72367    68487    68458

brand   ford   mini   opel  ...  aston-martin  tesla  hummer  isuzu    mg  \
model  67695  64446  59877  ...          2214   2206    1532   1448  1038

brand  ligier  rover  corvette  lada  cadillac
model     753    603       287   272       253

[1 rows x 57 columns]

       count          mean           std    min     25%      50%      75%  \
model   57.0  28633.561404  41410.185854  253.0  4854.0  13861.0  31336.0

            max
model  230990.0

• 1.4.2 Create a data frame P(1)
  Extraction of a list of classes and storage in CSV from the image directory.

df_P1 = create_data(FOLDER_P1_TRAIN)
df_P1.head()

	filename	brand	model
0	/mnt/data/dataset_v1/train/chevrolet_captiva/3...	chevrolet	chevrolet_captiva
1	/mnt/data/dataset_v1/train/chevrolet_captiva/2...	chevrolet	chevrolet_captiva
2	/mnt/data/dataset_v1/train/chevrolet_captiva/2...	chevrolet	chevrolet_captiva
3	/mnt/data/dataset_v1/train/chevrolet_captiva/1...	chevrolet	chevrolet_captiva
4	/mnt/data/dataset_v1/train/chevrolet_captiva/2...	chevrolet	chevrolet_captiva

• Structure and quick view P(1)

df_P1.nunique()

filename    130200
brand           54
model          651
dtype: int64

info_data(df_P1)

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 130200 entries, 0 to 130199
Data columns (total 3 columns):
 #   Column    Non-Null Count   Dtype
---  ------    --------------   -----
 0   filename  130200 non-null  object
 1   brand     130200 non-null  object
 2   model     130200 non-null  object
dtypes: object(3)
memory usage: 3.0+ MB
None

filename    0
brand       0
model       0
dtype: int64

brand  mercedes-benz    bmw  volkswagen  audi  fiat  ford  peugeot  citroen  \
model          22000  11600        8800  6000  5400  5200     4800     4600

brand  mini  nissan  ...  saab  rover  isuzu  iveco  ligier  caravans-wohnm  \
model  4600    4200  ...   400    200    200    200     200             200

brand   mg  bentley  tesla  hummer
model  200      200    200     200

[1 rows x 54 columns]

       count         mean          std    min    25%     50%     75%      max
model   54.0  2411.111111  3528.090331  200.0  600.0  1200.0  2750.0  22000.0

brand  mercedes-benz    bmw  volkswagen  audi  fiat  ford  peugeot  citroen  \
model          22000  11600        8800  6000  5400  5200     4800     4600

brand  mini  nissan  ...  saab  rover  isuzu  iveco  ligier  caravans-wohnm  \
model  4600    4200  ...   400    200    200    200     200             200

brand   mg  bentley  tesla  hummer
model  200      200    200     200

[1 rows x 54 columns]

       count         mean          std    min    25%     50%     75%      max
model   54.0  2411.111111  3528.090331  200.0  600.0  1200.0  2750.0  22000.0

• 1.4.3 Create a data frame P(2)
  Extraction of a list of classes and storage in CSV from the image directory.

• Train P(2)

df_P2_train = create_data(FOLDER_P2_TRAIN)
df_P2_train.head()

	filename	brand	model
0	/mnt/data/dataset_v2/train/chevrolet_captiva/3...	chevrolet	chevrolet_captiva
1	/mnt/data/dataset_v2/train/chevrolet_captiva/2...	chevrolet	chevrolet_captiva
2	/mnt/data/dataset_v2/train/chevrolet_captiva/2...	chevrolet	chevrolet_captiva
3	/mnt/data/dataset_v2/train/chevrolet_captiva/1...	chevrolet	chevrolet_captiva
4	/mnt/data/dataset_v2/train/chevrolet_captiva/2...	chevrolet	chevrolet_captiva

df_P2_train.nunique()

filename    65312
brand          43
model         387
dtype: int64

• Structure and quick view Train P(2)

info_data(df_P2_train)

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 65312 entries, 0 to 65311
Data columns (total 3 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   filename  65312 non-null  object
 1   brand     65312 non-null  object
 2   model     65312 non-null  object
dtypes: object(3)
memory usage: 1.5+ MB
None

filename    0
brand       0
model       0
dtype: int64

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           7273        5338  5000  3764  3727  3085     3031     2865

brand  ford  renault  ...  ssangyong  toyota  daihatsu  ds-automobiles  lexus  \
model  2573     2497  ...        352     345       344             343    324

brand  ferrari  bentley  maserati  iveco  dodge
model      174      170       169    105     96

[1 rows x 43 columns]

       count         mean          std   min    25%    50%     75%     max
model   43.0  1518.883721  1589.650384  96.0  431.0  905.0  2194.5  7273.0

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           7273        5338  5000  3764  3727  3085     3031     2865

brand  ford  renault  ...  ssangyong  toyota  daihatsu  ds-automobiles  lexus  \
model  2573     2497  ...        352     345       344             343    324

brand  ferrari  bentley  maserati  iveco  dodge
model      174      170       169    105     96

[1 rows x 43 columns]

       count         mean          std   min    25%    50%     75%     max
model   43.0  1518.883721  1589.650384  96.0  431.0  905.0  2194.5  7273.0

• Test P(2)

df_P2_test = create_data(FOLDER_P2_TEST)
df_P2_test.head()

	filename	brand	model
0	/mnt/data/dataset_v2/test/bmw_650/6362_1_43583...	bmw	bmw_650
1	/mnt/data/dataset_v2/test/bmw_650/6366_6_f378a...	bmw	bmw_650
2	/mnt/data/dataset_v2/test/bmw_650/6358_4_35abb...	bmw	bmw_650
3	/mnt/data/dataset_v2/test/bmw_650/6386_1_95445...	bmw	bmw_650
4	/mnt/data/dataset_v2/test/bmw_650/6408_4_57e9a...	bmw	bmw_650

df_P2_test.nunique()

filename    7257
brand         43
model        387
dtype: int64

• Structure and quick view Test P(2)

info_data(df_P2_test)

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 7257 entries, 0 to 7256
Data columns (total 3 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   filename  7257 non-null   object
 1   brand     7257 non-null   object
 2   model     7257 non-null   object
dtypes: object(3)
memory usage: 170.2+ KB
None

filename    0
brand       0
model       0
dtype: int64

brand  mercedes-benz  volkswagen  bmw  fiat  audi  mini  peugeot  citroen  \
model            826         574  552   418   398   349      338      307

brand  ford  opel  ...  daihatsu  lexus  ds-automobiles  ssangyong  saab  \
model   290   266  ...        42     39              38         35    30

brand  maserati  ferrari  bentley  iveco  dodge
model        20       18       18     13      9

[1 rows x 43 columns]

       count        mean         std  min   25%   50%    75%    max
model   43.0  168.767442  176.309905  9.0  53.5  87.0  241.5  826.0

brand  mercedes-benz  volkswagen  bmw  fiat  audi  mini  peugeot  citroen  \
model            826         574  552   418   398   349      338      307

brand  ford  opel  ...  daihatsu  lexus  ds-automobiles  ssangyong  saab  \
model   290   266  ...        42     39              38         35    30

brand  maserati  ferrari  bentley  iveco  dodge
model        20       18       18     13      9

[1 rows x 43 columns]

       count        mean         std  min   25%   50%    75%    max
model   43.0  168.767442  176.309905  9.0  53.5  87.0  241.5  826.0

• Merge Train & Test

join_df_P2 = pd.concat([df_P2_train, df_P2_test], axis=0)
join_df_P2.nunique()

filename    72569
brand          43
model         387
dtype: int64

info_data(join_df_P2)

<class 'pandas.core.frame.DataFrame'>
Int64Index: 72569 entries, 0 to 7256
Data columns (total 3 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   filename  72569 non-null  object
 1   brand     72569 non-null  object
 2   model     72569 non-null  object
dtypes: object(3)
memory usage: 2.2+ MB
None

filename    0
brand       0
model       0
dtype: int64

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           8099        5912  5552  4162  4145  3434     3369     3172

brand  ford  renault  ...  ssangyong  daihatsu  saab  ds-automobiles  lexus  \
model  2863     2749  ...        387       386   382             381    363

brand  ferrari  maserati  bentley  iveco  dodge
model      192       189      188    118    105

[1 rows x 43 columns]

       count         mean          std    min    25%    50%     75%     max
model   43.0  1687.651163  1765.634108  105.0  483.0  987.0  2443.0  8099.0

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           8099        5912  5552  4162  4145  3434     3369     3172

brand  ford  renault  ...  ssangyong  daihatsu  saab  ds-automobiles  lexus  \
model  2863     2749  ...        387       386   382             381    363

brand  ferrari  maserati  bentley  iveco  dodge
model      192       189      188    118    105

[1 rows x 43 columns]

       count         mean          std    min    25%    50%     75%     max
model   43.0  1687.651163  1765.634108  105.0  483.0  987.0  2443.0  8099.0

• 1.4.4 Create a data frame P(3)
  Extraction of a list of classes and storage in CSV from the image directory.

• Train P(3)

df_P3_train = create_data(FOLDER_P3_TRAIN)
df_P3_train.head()

	filename	brand	model
0	/mnt/data/dataset_v3/train/chevrolet_cruze/971...	chevrolet	chevrolet_cruze
1	/mnt/data/dataset_v3/train/chevrolet_cruze/949...	chevrolet	chevrolet_cruze
2	/mnt/data/dataset_v3/train/chevrolet_cruze/855...	chevrolet	chevrolet_cruze
3	/mnt/data/dataset_v3/train/chevrolet_cruze/857...	chevrolet	chevrolet_cruze
4	/mnt/data/dataset_v3/train/chevrolet_cruze/961...	chevrolet	chevrolet_cruze

df_P3_train.nunique()

filename    65312
brand          43
model         273
dtype: int64

• Structure and quick view Train P(3)

info_data(df_P3_train)

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 65312 entries, 0 to 65311
Data columns (total 3 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   filename  65312 non-null  object
 1   brand     65312 non-null  object
 2   model     65312 non-null  object
dtypes: object(3)
memory usage: 1.5+ MB
None

filename    0
brand       0
model       0
dtype: int64

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           7273        5338  5000  3764  3206  3085     3031     2865

brand  ford  renault  ...  saab  toyota  daihatsu  ds-automobiles  lexus  \
model  2573     2497  ...   352     345       344             343    324

brand  ferrari  bentley  maserati  iveco  dodge
model      174      170       169    105     96

[1 rows x 43 columns]

       count         mean          std   min    25%     50%     75%     max
model   43.0  1518.883721  1568.471188  96.0  433.0  1025.0  2194.5  7273.0

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           7273        5338  5000  3764  3206  3085     3031     2865

brand  ford  renault  ...  saab  toyota  daihatsu  ds-automobiles  lexus  \
model  2573     2497  ...   352     345       344             343    324

brand  ferrari  bentley  maserati  iveco  dodge
model      174      170       169    105     96

[1 rows x 43 columns]

       count         mean          std   min    25%     50%     75%     max
model   43.0  1518.883721  1568.471188  96.0  433.0  1025.0  2194.5  7273.0

• Test P(3)

df_P3_test = create_data(FOLDER_P3_TEST)
df_P3_test.nunique()

filename    7257
brand         43
model        273
dtype: int64

• Structure and quick view Test P(3)

info_data(df_P3_test)

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 7257 entries, 0 to 7256
Data columns (total 3 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   filename  7257 non-null   object
 1   brand     7257 non-null   object
 2   model     7257 non-null   object
dtypes: object(3)
memory usage: 170.2+ KB
None

filename    0
brand       0
model       0
dtype: int64

brand  mercedes-benz  volkswagen  bmw  audi  fiat  mini  peugeot  citroen  \
model            826         574  552   398   357   349      338      307

brand  ford  opel  ...  daihatsu  lexus  ds-automobiles  ssangyong  saab  \
model   290   266  ...        42     39              38         35    30

brand  maserati  bentley  ferrari  iveco  dodge
model        20       18       18     13      9

[1 rows x 43 columns]

       count        mean         std  min   25%   50%    75%    max
model   43.0  168.767442  173.979725  9.0  53.5  96.0  241.5  826.0

brand  mercedes-benz  volkswagen  bmw  audi  fiat  mini  peugeot  citroen  \
model            826         574  552   398   357   349      338      307

brand  ford  opel  ...  daihatsu  lexus  ds-automobiles  ssangyong  saab  \
model   290   266  ...        42     39              38         35    30

brand  maserati  bentley  ferrari  iveco  dodge
model        20       18       18     13      9

[1 rows x 43 columns]

       count        mean         std  min   25%   50%    75%    max
model   43.0  168.767442  173.979725  9.0  53.5  96.0  241.5  826.0

• Merge Train & Test P(3)

join_df_P3 = pd.concat([df_P3_train, df_P3_test], axis=0)
join_df_P3.nunique()

filename    72569
brand          43
model         273
dtype: int64

info_data(join_df_P3)

<class 'pandas.core.frame.DataFrame'>
Int64Index: 72569 entries, 0 to 7256
Data columns (total 3 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   filename  72569 non-null  object
 1   brand     72569 non-null  object
 2   model     72569 non-null  object
dtypes: object(3)
memory usage: 2.2+ MB
None

filename    0
brand       0
model       0
dtype: int64

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           8099        5912  5552  4162  3563  3434     3369     3172

brand  ford  renault  ...  ssangyong  daihatsu  saab  ds-automobiles  lexus  \
model  2863     2749  ...        387       386   382             381    363

brand  ferrari  maserati  bentley  iveco  dodge
model      192       189      188    118    105

[1 rows x 43 columns]

       count         mean          std    min    25%     50%     75%     max
model   43.0  1687.651163  1742.113192  105.0  483.0  1148.0  2443.0  8099.0

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           8099        5912  5552  4162  3563  3434     3369     3172

brand  ford  renault  ...  ssangyong  daihatsu  saab  ds-automobiles  lexus  \
model  2863     2749  ...        387       386   382             381    363

brand  ferrari  maserati  bentley  iveco  dodge
model      192       189      188    118    105

[1 rows x 43 columns]

       count         mean          std    min    25%     50%     75%     max
model   43.0  1687.651163  1742.113192  105.0  483.0  1148.0  2443.0  8099.0

2. EDA

• 2.1 Visualization
  • 2.1.1 Multivariable
    • 2.1.1.1 Box plots

• RD(0)

plot_multi_boxplot_swarmpplot(df_RD)

brand     abarth  alfa-romeo  aston-martin   audi  bentley     bmw  cadillac  \
filename   11350       17849          2214  81760     4854  147449       253
model      11350       17849          2214  81760     4854  147449       253
year       11350       17849          2214  81760     4854  147449       253

brand     caravans-wohnm  chevrolet  chrysler  ...  saab   seat  skoda  smart  \
filename            2975      15681     10579  ...  4996  31336  23021  11430
model               2975      15681     10579  ...  4996  31336  23021  11430
year                2975      15681     10579  ...  4996  31336  23021  11430

brand     ssangyong  subaru  suzuki  tesla  toyota  volkswagen
filename       8084   16632   28999   2206    8032      130423
model          8084   16632   28999   2206    8032      130423
year           8084   16632   28999   2206    8032      130423

[3 rows x 57 columns]

• P(1)

plot_multi_boxplot_swarmpplot(df_P1)

brand     abarth  alfa-romeo  aston-martin  audi  bentley    bmw  \
filename    1600        1600           400  6000      200  11600
model       1600        1600           400  6000      200  11600

brand     caravans-wohnm  chevrolet  chrysler  citroen  ...  saab  seat  \
filename             200       1800      1200     4600  ...   400  2200
model                200       1800      1200     4600  ...   400  2200

brand     skoda  smart  ssangyong  subaru  suzuki  tesla  toyota  volkswagen
filename   1400   1000        800    1200    2600    200     600        8800
model      1400   1000        800    1200    2600    200     600        8800

[2 rows x 54 columns]

• P(2)

plot_multi_boxplot_swarmpplot(join_df_P2)

brand     abarth  alfa-romeo  audi  bentley   bmw  chevrolet  chrysler  \
filename     586        1356  4162      188  5552        956       764
model        586        1356  4162      188  5552        956       764

brand     citroen  dacia  daihatsu  ...  renault  saab  seat  skoda  smart  \
filename     3172    782       386  ...     2749   382  1332   1158    580
model        3172    782       386  ...     2749   382  1332   1158    580

brand     ssangyong  subaru  suzuki  toyota  volkswagen
filename        387     961    1513     389        5912
model           387     961    1513     389        5912

[2 rows x 43 columns]

• P(3)

plot_multi_boxplot_swarmpplot(join_df_P3)

brand     abarth  alfa-romeo  audi  bentley   bmw  chevrolet  chrysler  \
filename    1168        1356  4162      188  5552        956       764
model       1168        1356  4162      188  5552        956       764

brand     citroen  dacia  daihatsu  ...  renault  saab  seat  skoda  smart  \
filename     3172    782       386  ...     2749   382  1332   1158    580
model        3172    782       386  ...     2749   382  1332   1158    580

brand     ssangyong  subaru  suzuki  toyota  volkswagen
filename        387     961    1513     389        5912
model           387     961    1513     389        5912

[2 rows x 43 columns]

• 2.1.1.2 Bar Plots
  • RD(0)

all_class_plots(df_RD)

Statistics

df_RD.describe()

	filename	brand	model	year
count	1632113	1632113	1632113	1632113
unique	1632113	57	823	19
top	/mnt/data/nahuel/images/lancia_delta_2011/1780...	mercedes-benz	500	2018
freq	1	230990	6271	129294

df_RD.groupby(by = ["brand",'year']).describe()

		filename				model
		count	unique	top	freq	count	unique	top	freq
brand	year
abarth	2008	510	510	/mnt/data/nahuel/images/abarth_500_2008/221_7_...	1	510	2	500	264
	2009	514	514	/mnt/data/nahuel/images/abarth_500_2009/220_5_...	1	514	2	grande-punto	281
	2010	455	455	/mnt/data/nahuel/images/abarth_500_2010/184_2_...	1	455	2	500	312
	2011	759	759	/mnt/data/nahuel/images/abarth_500_2011/157_5_...	1	759	3	500c	343
	2012	746	746	/mnt/data/nahuel/images/abarth_500c_2012/305_1...	1	746	3	500	350
...	...	...	...	...	...	...	...	...	...
volkswagen	2014	9251	9251	/mnt/data/nahuel/images/volkswagen_passat-vari...	1	9251	35	jetta	424
	2015	9739	9739	/mnt/data/nahuel/images/volkswagen_golf_2015/2...	1	9739	38	cc	469
	2016	8551	8551	/mnt/data/nahuel/images/volkswagen_maggiolino_...	1	8551	37	jetta	420
	2017	7776	7776	/mnt/data/nahuel/images/volkswagen_jetta_2017/...	1	7776	32	golf-variant	457
	2018	7624	7624	/mnt/data/nahuel/images/volkswagen_crafter_201...	1	7624	29	t-roc	383

784 rows × 8 columns

• P(1)

all_class_plots(df_P1)

Statistics

df_P1.describe()

	filename	brand	model
count	130200	130200	130200
unique	130200	54	651
top	/mnt/data/dataset_v1/train/hyundai_terracan/82...	mercedes-benz	subaru_forester
freq	1	22000	200

df_P1.groupby(by = ["brand",'model']).describe()

		filename
		count	unique	top	freq
brand	model
abarth	abarth_124-spider	200	200	/mnt/data/dataset_v1/train/abarth_124-spider/8...	1
	abarth_500	200	200	/mnt/data/dataset_v1/train/abarth_500/211_11_1...	1
	abarth_500c	200	200	/mnt/data/dataset_v1/train/abarth_500c/280_6_e...	1
	abarth_595	200	200	/mnt/data/dataset_v1/train/abarth_595/841_5_5e...	1
	abarth_595-competizione	200	200	/mnt/data/dataset_v1/train/abarth_595-competiz...	1
...	...	...	...	...	...
volkswagen	volkswagen_tiguan	200	200	/mnt/data/dataset_v1/train/volkswagen_tiguan/6...	1
	volkswagen_touareg	200	200	/mnt/data/dataset_v1/train/volkswagen_touareg/...	1
	volkswagen_touran	200	200	/mnt/data/dataset_v1/train/volkswagen_touran/1...	1
	volkswagen_transporter	200	200	/mnt/data/dataset_v1/train/volkswagen_transpor...	1
	volkswagen_up	200	200	/mnt/data/dataset_v1/train/volkswagen_up/6808_...	1

651 rows × 4 columns

• P(2)

all_class_plots(join_df_P2)

join_df_P2.describe()

	filename	brand	model
count	72569	72569	72569
unique	72569	43	387
top	/mnt/data/dataset_v2/train/bmw_530/4193_3_284a...	mercedes-benz	chrysler_voyager
freq	1	8099	200

join_df_P2.groupby(by = ["brand",'model']).describe()

		filename
		count	unique	top	freq
brand	model
abarth	abarth_500	197	197	/mnt/data/dataset_v2/train/abarth_500/57_3_a0b...	1
	abarth_500c	195	195	/mnt/data/dataset_v2/test/abarth_500c/254_7_e8...	1
	abarth_595-turismo	194	194	/mnt/data/dataset_v2/train/abarth_595-turismo/...	1
alfa-romeo	alfa-romeo_147	193	193	/mnt/data/dataset_v2/train/alfa-romeo_147/153_...	1
	alfa-romeo_156	196	196	/mnt/data/dataset_v2/train/alfa-romeo_156/783_...	1
...	...	...	...	...	...
volkswagen	volkswagen_t5-multivan	187	187	/mnt/data/dataset_v2/train/volkswagen_t5-multi...	1
	volkswagen_tiguan	187	187	/mnt/data/dataset_v2/train/volkswagen_tiguan/6...	1
	volkswagen_touareg	189	189	/mnt/data/dataset_v2/train/volkswagen_touareg/...	1
	volkswagen_touran	192	192	/mnt/data/dataset_v2/train/volkswagen_touran/1...	1
	volkswagen_transporter	170	170	/mnt/data/dataset_v2/train/volkswagen_transpor...	1

387 rows × 4 columns

• P(3)

all_class_plots(join_df_P3)

join_df_P3.describe()

	filename	brand	model
count	72569	72569	72569
unique	72569	43	273
top	/mnt/data/dataset_v3/train/chrysler_300c/787_6...	mercedes-benz	mercedes-benz_e_class
freq	1	8099	2509

join_df_P3.groupby(by = ["brand",'model']).describe()

		filename
		count	unique	top	freq
brand	model
abarth	abarth_500_series	1168	1168	/mnt/data/dataset_v3/train/abarth_500_series/1...	1
alfa-romeo	alfa-romeo_147	193	193	/mnt/data/dataset_v3/train/alfa-romeo_147/207_...	1
	alfa-romeo_156	196	196	/mnt/data/dataset_v3/train/alfa-romeo_156/806_...	1
	alfa-romeo_159	195	195	/mnt/data/dataset_v3/train/alfa-romeo_159/100_...	1
	alfa-romeo_giulietta	194	194	/mnt/data/dataset_v3/train/alfa-romeo_giuliett...	1
...	...	...	...	...	...
volkswagen	volkswagen_sharan	187	187	/mnt/data/dataset_v3/train/volkswagen_sharan/4...	1
	volkswagen_t5	727	727	/mnt/data/dataset_v3/train/volkswagen_t5/9587_...	1
	volkswagen_tiguan	187	187	/mnt/data/dataset_v3/train/volkswagen_tiguan/6...	1
	volkswagen_touareg	189	189	/mnt/data/dataset_v3/train/volkswagen_touareg/...	1
	volkswagen_touran	192	192	/mnt/data/dataset_v3/train/volkswagen_touran/1...	1

273 rows × 4 columns

• 2.1.1.3 Stacked graphics

Stacking Per brand

• RD(0)

Stacking_graphs(df_RD,"brand")

• P(1)

Stacking_graphs(df_P1,"brand")

• P(2)

Stacking_graphs(join_df_P2,"brand")

• P(3)

Stacking_graphs(join_df_P3,"brand")

Stacking Per Model

• RD(0)

Stacking_graphs(df_RD,"model")

• p(1)

Stacking_graphs(df_P1,"model",k=False)

• P(2)

Stacking_graphs(join_df_P2,"model")

• P(3)

Stacking_graphs(join_df_P3,"model")

• 2.1.1.4 Correlation matrix
  • RD(0)

plot_matrix(df_RD,"model")

• P(1)

plot_matrix(df_P1,"brand")

• P(2)

plot_matrix(join_df_P2,"model")

• P(3)

plot_matrix(join_df_P3,"model")

• 2.1.1.5 heatmap
  • RD(0)

plot_matrix(df_RD,"brand", 2)

• P(1)

plot_matrix(df_P1,"brand", 2)

• P(2)

plot_matrix(join_df_P2,"brand", 2)

• P(3)

plot_matrix(join_df_P3,"brand", 2)

• 2.1.2 Univariable
  • 2.1.2.1 Top 25 Distribution

• Top 25 most significant filename with their absolute and relative frequency.
• RD(0)

univ_dist(df_RD,'filename')

• P(1)

univ_dist(df_P1,'filename')

• P(2)

univ_dist(join_df_P2,'filename')

• P(3)

univ_dist(join_df_P3,'filename')

• Top 25 most significant brand with their absolute and relative frequency.
• RD(0)

univ_dist(df_RD,'brand')

brand  mercedes-benz     bmw  volkswagen   audi   fiat  citroen  renault  \
model         230990  147449      130423  81760  72367    68487    68458

brand   ford   mini   opel  ...  suzuki  mazda  mitsubishi  porsche  \
model  67695  64446  59877  ...   28999  28299       27097    26219

brand  land-rover  skoda  honda   jeep  alfa-romeo  jaguar
model       24351  23021  19862  18143       17849   17034

[1 rows x 25 columns]

       mercedes-benz      bmw  volkswagen      audi      fiat   citroen  \
brand      14.152819  9.03424    7.991052  5.009457  4.433945  4.196217

       renault      ford      mini     opel  ...    suzuki     mazda  \
brand  4.19444  4.147691  3.948624  3.66868  ...  1.776776  1.733887

       mitsubishi   porsche  land-rover     skoda    honda      jeep  \
brand     1.66024  1.606445    1.491992  1.410503  1.21695  1.111626

       alfa-romeo    jaguar
brand    1.093613  1.043678

[1 rows x 25 columns]

• P(1)

univ_dist(df_P1,'brand')

brand  mercedes-benz  volkswagen  bmw  fiat  audi  mini  peugeot  citroen  \
model            826         574  552   418   398   349      338      307

brand  ford  opel  ...  seat  alfa-romeo  mitsubishi  porsche  mazda  skoda  \
model   290   266  ...   152         139         127      126    115     96

brand  chevrolet  subaru  land-rover  jaguar
model         87      86          82      77

[1 rows x 25 columns]

       mercedes-benz  volkswagen       bmw      fiat     audi     mini  \
brand      11.382114    7.909605  7.606449  5.759956  5.48436  4.80915

        peugeot   citroen      ford      opel  ...      seat  alfa-romeo  \
brand  4.657572  4.230398  3.996142  3.665426  ...  2.094529    1.915392

       mitsubishi   porsche     mazda     skoda  chevrolet    subaru  \
brand    1.750034  1.736255  1.584677  1.322861   1.198842  1.185063

       land-rover    jaguar
brand    1.129944  1.061045

[1 rows x 25 columns]

• P(2)

univ_dist(join_df_P2,'brand')

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           8099        5912  5552  4162  4145  3434     3369     3172

brand  ford  renault  ...  alfa-romeo  seat  mitsubishi  skoda  porsche  \
model  2863     2749  ...        1356  1332        1319   1158     1151

brand  mazda  land-rover  subaru  chevrolet  dacia
model   1148         987     961        956    782

[1 rows x 25 columns]

       mercedes-benz  volkswagen      bmw      audi      fiat      mini  \
brand      11.160413    8.146729  7.65065  5.735231  5.711805  4.732048

        peugeot   citroen      ford   renault  ...  alfa-romeo      seat  \
brand  4.642478  4.371012  3.945211  3.788119  ...    1.868566  1.835494

       mitsubishi     skoda   porsche     mazda  land-rover    subaru  \
brand    1.817581  1.595723  1.586077  1.581943    1.360085  1.324257

       chevrolet     dacia
brand   1.317367  1.077595

[1 rows x 25 columns]

• P(3)

univ_dist(join_df_P3,'brand')

brand  mercedes-benz  volkswagen   bmw  audi  fiat  mini  peugeot  citroen  \
model           8099        5912  5552  4162  3563  3434     3369     3172

brand  ford  renault  ...  alfa-romeo  seat  mitsubishi  abarth  skoda  \
model  2863     2749  ...        1356  1332        1319    1168   1158

brand  porsche  mazda  land-rover  subaru  chevrolet
model     1151   1148         987     961        956

[1 rows x 25 columns]

       mercedes-benz  volkswagen      bmw      audi     fiat      mini  \
brand      11.160413    8.146729  7.65065  5.735231  4.90981  4.732048

        peugeot   citroen      ford   renault  ...  alfa-romeo      seat  \
brand  4.642478  4.371012  3.945211  3.788119  ...    1.868566  1.835494

       mitsubishi    abarth     skoda   porsche     mazda  land-rover  \
brand    1.817581  1.609503  1.595723  1.586077  1.581943    1.360085

         subaru  chevrolet
brand  1.324257   1.317367

[1 rows x 25 columns]

• Top 25 most significant model with their absolute and relative frequency.
• RD(0)

univ_dist(df_RD,'model')

model   500  c-220  corsa  cooper  others  golf  doblo  astra  golf-variant  \
model  6271   6071   6069    5972    5947  5811   5770   5757          5717

model  fiesta  ...   330  c-200    c5  octavia  scenic  e-220  jimny  punto  \
model    5583  ...  5521   5503  5486     5438    5435   5428   5375   5340

model  ibiza   320
model   5338  5257

[1 rows x 25 columns]

            500     c-220     corsa    cooper    others      golf     doblo  \
model  0.384226  0.371972  0.371849  0.365906  0.364374  0.356042  0.353529

          astra  golf-variant    fiesta  ...       330    c-200        c5  \
model  0.352733      0.350282  0.342072  ...  0.338273  0.33717  0.336129

        octavia    scenic     e-220     jimny     punto     ibiza       320
model  0.333188  0.333004  0.332575  0.329328  0.327183  0.327061  0.322098

[1 rows x 25 columns]

• P(1)

univ_dist(df_P1,'model')

model  volkswagen_up  ford_focus-c-max  ford_transit-custom  \
model            200               200                  200

model  ford_transit-courier  ford_transit-connect  ford_transit  \
model                   200                   200           200

model  ford_tourneo-custom  ford_tourneo-courier  ford_tourneo-connect  \
model                  200                   200                   200

model  ford_tourneo  ...  ford_kuga  ford_grand-c-max  ford_galaxy  \
model           200  ...        200               200          200

model  ford_fusion  honda_accord  honda_civic  honda_cr-v  hyundai_i10  \
model          200           200          200         200          200

model  hyundai_santa-fe  hyundai_matrix
model               200             200

[1 rows x 25 columns]

       subaru_forester  honda_fr-v  audi_a5  bmw_218  peugeot_1007  \
model          0.15361     0.15361  0.15361  0.15361       0.15361

       mercedes-benz_c-270  kia_niro  volkswagen_t6-transporter  \
model              0.15361   0.15361                    0.15361

       abarth_595-competizione  citroen_c-crosser  ...  skoda_citigo  \
model                  0.15361            0.15361  ...       0.15361

       peugeot_407  ds-automobiles_ds-5  mercedes-benz_sl-55-amg  \
model      0.15361              0.15361                  0.15361

       nissan_nv400  nissan_almera-tino  mercedes-benz_c-63-amg  \
model       0.15361             0.15361                 0.15361

       volkswagen_tiguan  isuzu_d-max  porsche_panamera
model            0.15361      0.15361           0.15361

[1 rows x 25 columns]

• P(2)

univ_dist(join_df_P2,'model')

model  chrysler_voyager  mercedes-benz_b-170  mini_one  audi_tt  peugeot_207  \
model               200                  199       199      199          199

model  volkswagen_jetta  kia_carens  volkswagen_fox  mitsubishi_colt  \
model               199         199             198              198

model  toyota_prius  ...  nissan_370z  nissan_almera  opel_agila  opel_meriva  \
model           198  ...          197            197         197          197

model  peugeot_1007  peugeot_206  fiat_croma  peugeot_307  ssangyong_korando  \
model           197          197         197          197                197

model  suzuki_sx4
model         197

[1 rows x 25 columns]

       chrysler_voyager  volkswagen_jetta  mini_one   audi_tt  peugeot_207  \
model            0.2756          0.274222  0.274222  0.274222     0.274222

       mercedes-benz_b-170  kia_carens  volkswagen_fox  toyota_prius  \
model             0.274222    0.274222        0.272844      0.272844

        mazda_3  ...  peugeot_206  ssangyong_korando  mercedes-benz_s-320  \
model  0.272844  ...     0.271466           0.271466             0.271466

       opel_agila  mercedes-benz_c-350  suzuki_sx4  nissan_370z  \
model    0.271466             0.271466    0.271466     0.271466

       nissan_almera  mercedes-benz_200  fiat_croma
model       0.271466           0.271466    0.271466

[1 rows x 25 columns]

• P(3)

univ_dist(join_df_P3,'model')

model  mercedes-benz_e_class  audi_a_series  mercedes-benz_c_class  \
model                   2509           1700                   1659

model  mini_cooper  abarth_500_series  bmw_300_series  bmw_500_series  \
model         1344               1168            1158            1152

model  mercedes-benz_a_class  bmw_100_series  mini_cooper-countryman  ...  \
model                    964             954                     934  ...

model  volkswagen_passat  audi_tt_series  volkswagen_beetle  audi_r_series  \
model                579             579                577            575

model  mercedes-benz_m_class  mercedes-benz_sl_class  mercedes-benz_s_class  \
model                    575                     573                    572

model  bmw_700_series  opel_van  fiat_ducato
model             562       485          475

[1 rows x 25 columns]

       mercedes-benz_e_class  audi_a_series  mercedes-benz_c_class  \
model               3.457399       2.342598                 2.2861

       mini_cooper  abarth_500_series  bmw_300_series  bmw_500_series  \
model      1.85203           1.609503        1.595723        1.587455

       mercedes-benz_a_class  bmw_100_series  mini_cooper-countryman  ...  \
model               1.328391        1.314611                1.287051  ...

       volkswagen_passat  audi_tt_series  volkswagen_beetle  \
model           0.797861        0.797861           0.795105

       mercedes-benz_m_class  audi_r_series  mercedes-benz_sl_class  \
model               0.792349       0.792349                0.789593

       mercedes-benz_s_class  bmw_700_series  opel_van  fiat_ducato
model               0.788215        0.774435  0.668329     0.654549

[1 rows x 25 columns]

Top 19 most significant year with their absolute and relative frequency.

• year only has 19 dates in Raw Data

univ_dist(df_RD,'year')

year     2018    2017    2015    2016    2014    2013   2012   2011   2009  \
model  129294  125332  117000  115569  114626  105396  98205  95665  91686

year    2008   2010   2007   2006   2005   2004   2003   2002   2001  ceed
model  90892  90692  85499  77928  76332  65332  55983  48257  46009  2416

          2018      2017      2015      2016      2014      2013      2012  \
year  7.921878  7.679125  7.168621  7.080944  7.023166  6.457641  6.017047

         2011      2009      2008      2010      2007      2006      2005  \
year  5.86142  5.617626  5.568977  5.556723  5.238547  4.774669  4.676882

          2004      2003      2002      2001      ceed
year  4.002909  3.430093  2.956719  2.818984  0.148029

• 2.2 Experiments

List extracted from all folders in the s3 bucket, in csv format.
This dataset contains information extracted from the bucket before it was downloaded, and was compared to a downloaded list. It was found that there were empty folders with no images, some with size = 0 and some corrupted files that were checked at download time.

all_data = pd.read_csv('./list_s3_cars.csv')
all_data.head()

	Key	LastModified	ETag	Size	StorageClass	OwnerDisplayName	OwnerID
0	eu-car-dataset/images/abarth_124-spider_2016/	1/1/0001 00:00:00	NaN	0	STANDARD	unknown	unknown
1	eu-car-dataset/images/abarth_124-spider_2017/	1/1/0001 00:00:00	NaN	0	STANDARD	unknown	unknown
2	eu-car-dataset/images/abarth_124-spider_2018/	1/1/0001 00:00:00	NaN	0	STANDARD	unknown	unknown
3	eu-car-dataset/images/abarth_500_2008/	1/1/0001 00:00:00	NaN	0	STANDARD	unknown	unknown
4	eu-car-dataset/images/abarth_500_2009/	1/1/0001 00:00:00	NaN	0	STANDARD	unknown	unknown

all_data.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 6624 entries, 0 to 6623
Data columns (total 7 columns):
 #   Column            Non-Null Count  Dtype
---  ------            --------------  -----
 0   Key               6624 non-null   object
 1   LastModified      6624 non-null   object
 2   ETag              1 non-null      object
 3   Size              6624 non-null   int64
 4   StorageClass      6624 non-null   object
 5   OwnerDisplayName  6624 non-null   object
 6   OwnerID           6624 non-null   object
dtypes: int64(1), object(6)
memory usage: 362.4+ KB

• You can see that we have 6624 directories in the image bucket

• 2.2.1 Missing or corrupted data
  Empty or corrupted files : Browsing the volvo class, 162 empty folders are found.

all_data = pd.read_csv('./list_s3_cars.csv')
filter_data_missing = all_data[6462:]
filter_data_missing.Key.describe()

count                                        162
unique                                       162
top       eu-car-dataset/images/volvo_xc70_2004/
freq                                           1
Name: Key, dtype: object

• Empty folders are checked
• As a matter of time, it was decided to eliminate all empty and corrupted classes.
• The Volvo class is one of them
• If necessary, there was talk of downloading images from an api to improve the model.
• The same criteria will be used for all empty classes.

• 2.2.2 About models

In the search for the best cleaning model for the preprocessing, we created our own sequential model with keras and tested other architectures and techniques to achieve better performance, models such as yolo5, yolo7, Mobilenet, Mobilenet_v2, Mobilenet_v3, Densenet. Project

3 . Pandas-profiling

Generate profile reports from a DataFrame of pandas

• 3.1 Report RD(0)

profile_name = 'Raw Data'
profile = ProfileReport(df_RD,
                       title="TEAM 1 : Raw Data "+str(datetime.datetime.today().strftime('%Y-%m-%d')))
print('---Saving profile...')
# Save profile
profile.to_file(output_file=os.getcwd()+'/'+profile_name+str(datetime.datetime.today().strftime('%Y-%m-%d')))

---Saving profile...

profile.to_notebook_iframe()

• 3.2 Report P(1)

profile_name_ = 'Pre-processed 1'
profile_ = ProfileReport(df_P1,
                       title="TEAM 1 : Pre-processed 1 "+str(datetime.datetime.today().strftime('%Y-%m-%d')))
print('---Saving profile...')
# Save profile
profile_.to_file(output_file=os.getcwd()+'/'+profile_name_+str(datetime.datetime.today().strftime('%Y-%m-%d')))

---Saving profile...

profile_.to_notebook_iframe()

• 3.3 Report P(2)

profile_name__ = 'Pre-processed 2'
profile__ = ProfileReport(join_df_P2,
                       title="TEAM 1 : Pre-processed 2 "+str(datetime.datetime.today().strftime('%Y-%m-%d')))
print('---Saving profile...')
# Save profile
profile__.to_file(output_file=os.getcwd()+'/'+profile_name__+str(datetime.datetime.today().strftime('%Y-%m-%d')))

---Saving profile...

profile__.to_notebook_iframe()

• 3.4 Report P(3)

profile_name___ = 'Pre-processed 3'
profile___ = ProfileReport(join_df_P3,
                       title="TEAM 1 : Pre-processed 3 "+str(datetime.datetime.today().strftime('%Y-%m-%d')))
print('---Saving profile...')
# Save profile
profile___.to_file(output_file=os.getcwd()+'/'+profile_name___+str(datetime.datetime.today().strftime('%Y-%m-%d')))

---Saving profile...

profile___.to_notebook_iframe()

4. Resources

Methodology(IBM)

Libs

AWS_Reference
matplotlib
seaborn
pandas
pandas-profiling
PIL
glob
sys
os
datetime
pathlib
cv2
numpy
random
tensorflow
warnings
Models_Keras

Papers

YOLOv5
YOLOv7
MobileNets
MobileNets_V2
MobileNets_v3

5. Conclusions

5.1 Research

• We always research and compare results and take the most significant values from unit tests.

5.2 Raw Data

• The raw data presents more than 1 million images, not all of which are autos.
• Grouping classes to remove corrupted files and non-car images will be our first approach.

5.3 Preprocessing

• Elimination of images: For the first preprocessing we trained a model with our own images for car and non-car classification.
• Reduction of classes: The criterion used was to stay with 200 model classes. all < 200 are eliminated, so the reduction of models remained at P1 651 , P2 387 & P3 273 .
• missing values: Empty folders, corrupted images, missing classes, corrupted files will be deleted.

5.4 Final conclusions

Carlos
The graphs show an improvement with data processing by filtering quality data, this will give us a good model and improve our results.

Nico
The quality of the source data, establish the need to make some decisions, the reduction of classes is one of them, in addition to balancing the classes establishing a total number of images for each one of them.

Enzo
To better balance the data we could use clustering and improve the data if we look for more images.

Jhoel
Corrupted data and missing images should be discarded to avoid bias.

Agus
There are images that cannot be opened, with a script we could delete them to avoid time reducing the size of the data.

Nahu
To balance the data we would have to think of a criterion and filter out everything that is not a car, it will be necessary to use several models.

---

---
